Bag series
Applications
Granules, powders, liquids, coffee, candy, pet food, etc. Food & non-food.
Granules, powders, liquids, coffee, candy, pet food, etc. Food & non-food.
Model :
DB-300
- 1Easy operation adjustment & low maintenance cost
- 2Adapt to a variety of sizes of bags
- 3No bags, no materials
- 4Safety door
- 5SS304 body and contact parts
| Specifications | DB-300 TYPE |
|---|---|
| Speed | 5 - 15 minute / package |
| Bag Size |
100 mm < Width < 300 mm 100 mm < Length < 300 mm |
| Power Supply | 220V，50Hz / 60Hz，single-phase，1.5 Kw |
| Air | 0.5 cubic meter / minute，0.65 megapa |
| Machine Dimesion | Length:1750 x Width:510 x Height:1300 mm |
| Electronic |
Japan Mitsubishi PLC Japan Omron PID temperature control Taiwan Delta color touch screen |
| Pneumatic |
Taiwan Air TAC cylinder complete set Sweden PIAB vacuum generator |
All specifications and designs are subject to change without notice.
Sub bag type:
- 1Trilateral seal
- 2Stand-up pouch
- 3Zipper bag
